UHF Dual Ferrite Isolator

380-470 MHz, > 75 dB typical isolation @ +25 °C, 150 W, < 1.0 dB IL, 1.5:1 VSWR.

Frequency

380–470 MHz
Power

15 W
Isolation

> 75 dB
Insertion loss

< 1 dB
Connector

N-Female
Weight

1.3 kg

Request quote

Specifications

Electrical

Frequency range	380–470 MHz
Power handling	15 W
Insertion loss	<1 dB
Tx-Rx isolation	>75 dB
VSWR (max)	1.5
Impedance	5 Ω

Mechanical

RF connectors	N-Female
Weight	1.3 kg
Dimensions (H × W × D)	51 × 114 × 160 mm

Configuration

Isolation 25c Db	75
Isolation 0 60c Db	40
Isolation Neg10 0c Db	35
Power W	150
Temperature Range	-10°C to +60°C

Verified 2026-05-06 · ALUNOR RF Engineering · source: ALUNOR RF Technical Catalogue 2026-01-21

All measurements at 25 °C, 50 Ω, unless otherwise noted.

Why this product

01

Dual-stage ferrite — > 75 dB typical isolation at +25 °C
02

150 W continuous duty, < 1.0 dB insertion loss
03

Documented temperature-dependent isolation curve

Technical brief

Two-stage ferrite isolator

Dual-stage construction stacks isolation: > 75 dB typical at +25 °C, with documented degradation outside the room-temperature window:
- 0 °C to +60 °C: > 40 dB
- -10 °C to 0 °C: > 35 dB

Protects transmitter PA stages from reflected power; prevents transmitter-to-transmitter intermod at multi-carrier sites.

Solves these problems

Primary recommendation

Protecting transmitter PA stages from reflected power and inter-system intermod

A failed antenna, a wet feedline connector, or a strong nearby transmitter can drive reflected power back into the PA — and at multi-carrier sites, two transmitters mixing in a non-linear element generate intermod products that fall back into your receiver band.
